西门子伺服电机1PH8087-1UF02-0LA1

SIMOTICS M Compact induction
motor 1500rpm, 3.7kW, 24Nm,
10A, 336V 1750rpm, 4.3kW, 23Nm,
10A, 396V 2000rpm, 4.9kW, 23Nm,
10A, 435V forced ventilation;
direction of air flow DE-->
NDE; Degree of protection IP55
Incremental encoder 20-bit
Without commutation position
(encoder IN20DQ) with
DRIVE-CLiQ interface
DESIGN IM B5 (IMV 1,IM V3)
PLAIN SHAFT WITHOUT FITTED KEY;
BEARING: PERFORMANCE, VIBRATION
SEVERITY GRADE SPECIAL/B; SHAFT
A. FLANGE ACCURACY GR. SPECIAL
TERMINAL BOX (ABOVE) CABLE
ENTRY ON THE RIGHT SIGNAL
CONNECTION D-END
